Mitsuwa ChemicalCo.,Ltd.
Philippines
Mold/Jig
| Electric discharge machine(EDM) | 1 |
|---|---|
| Drilling EDM | 1 |
| Wirecutting machine(EDW) | 1 |
| Micro machining machine | 1 |
| Laser welding machine | 1 |
| NC milling machine(Numerical) | 1 |
| Clipika ace ultrasonic machine | 2 |
| Manual milling machine | 2 |
| Chamfer Machine | 1 |
| Band saw machine | 2 |
| Fine cutting machine | 1 |
| Lathe machine | 3 |
| Sand blast machine | 1 |
| Drill press machine | 2 |
| Belt sander | 1 |
| Surface grinding machine(Manual) | 2 | Panel saw machine | 1 |
| 3D-CAM | 1 |
| Mold design | 1 |
Injection
Vertical type
| 5t | 5 |
|---|---|
| 14t | 3 |
| 20t | 2 |
| 40t | 1 |
| Subtotal | 11 |
Horizontal type Single Injection
| 15t | 5 |
|---|---|
| 30t | 1 |
| 40t | 1 |
| 50t | 6 |
| 100t | 11 |
| 150t | 10 |
| 300t | 2 |
| Subtotal | 36 |
Double injection
| 120t | 6 |
|---|---|
| 130t | 5 |
| 140t | 1 |
| Subtotal | 12 |
| Total | 59 |
|---|
Coating
| Clean room | 3 |
|---|---|
| Automatic coating robot | 5 |
| Automatic supply equipment | 3 |
| Hotbath oven | 3 |
Printing
| Silkscreen | 3 |
|---|---|
| Pad print | 4 |
| Converyor oven | 1 |
Laser Marking
| Laser marker | 5 |
|---|
Inspection
| 3 dimensional measuring device | 8 |
|---|---|
| Camera inspection machine | 10 |
| Colorimeter | 1 |
| Particle counter | 1 |
Other
| Hotbath oven(Injection) | 4 |
|---|---|
| Assembly inspection line | 7 |
| Grease paint machine | 2 |
| Low and High temperature hotbath oven |
1 |
| Ultra-violet curing machine | 1 |
| Terminal cutting machine | 3 |
| Stereomicroscope | 25 |
Thailand
Mold/Jig
| Electric discharge machine(EDM) | 1 |
|---|---|
| Wirecutting machine(EDW) | 1 |
| Small hole drilling(EDM) | 1 |
| Laser welding machine | 1 |
| Clipika ace ultrasonic machine | 1 |
| Manual milling machine | 3 |
| Surface grinding machine(Manual) | 1 |
| Chamfer Machine | 1 |
| Band saw machine | 1 |
| Fine cutting machine | 1 |
| Cutting machine | 1 |
| Lathe machine | 1 |
| Engraving machine | 2 |
| Drill press machine | 3 |
| Sand blast machine | 1 |
| Grinder machine | 1 |
| Mill grind machine | 3 |
| Belt sander | 1 |
| 3D_CAD | 3 |
| 3D_CAM | 1 |
| Mold design | 2 |
| Mold flow | 1 |
Injection
| 15t | 1 |
|---|---|
| 30t | 1 |
| 50t | 2 |
| 100t | 6 |
| 150t | 3 |
| 300t | 4 |
| Two-color | 3 |
| Total | 20 |
Coating
| Clean room | 1 |
|---|---|
| Automatic coating robot | 2 |
| Automatic supply equipment | 2 |
| Hotbath oven | 1 |
Printing
| Silkscreen | 3 |
|---|---|
| Pad print | 7 |
Hot stamp
| Hot stamp | 2 |
|---|
Laser Marking
| Laser marker | 2 |
|---|
Inspection
| 3 dimensional measuring device | 3 |
|---|---|
| Camera inspection machine | 4 |
| Colorimeter | 1 |
| Gloss meter | 1 |
| Particle counter | 1 |
Other
| Hotbath oven | 1 |
|---|---|
| Assembly inspection line | 4 |
| Grease paint machine | 1 |
| Low and High temperature hotbath oven |
1 |
